The Minimax 50 Square floor drain has a 50 mm side outlet and a low total height of 86mm. It is suitable for installation in concrete joists with a tiled floor finish. The Minimax Square floor drain comes complete with a removable NOOD water trap and square stainless steel grate for tiled floors. The NOOD water trap is a mechanical trap which closes when there is no water present, thus preventing any foul air from escaping through the drain. It is not suitable for installation underneath a bath tub.
- Low built
Item Number
153462-E
Floor Construction
Concrete flooring
Floor Covering
Tiles
Function
Side outlet
Item Color
Grey
Material
PP, Stainless steel 1.4301
Outlet Dimension
Ø50 mm
Pressure Flow Temp
0,8 l/s
Size
130
Version
With NOOD water trap
