The Ymer 75 Side floor drain with Nordsjön Support has a 75mm side outlet. It is suitable for installation with the Nordsjön Support in concrete joists. The Ymer floor drain comes complete with a removable water trap, clamping ring and plastic grate. It also comes with a protective cover that is intended to prevent any concrete or debris from installation from entering the drain. The floor drain is manufactured in weldable PEH plastic.
The automatic clamping ring is used for both sealing membrane and vinyl flooring. It is a self-adjusting clamping ring for vinyl flooring with a thickness of 1,5 mm to 2 mm.
The automatic clamping ring is used for both sealing membrane and vinyl flooring. It is a self-adjusting clamping ring for vinyl flooring with a thickness of 1,5 mm to 2 mm.
- Comes complete with floor drain and floor drain fixture
- Easily adjustable
- Ensures that the floor drain is mounted straight
- Made of ABS, which provides good strength even at low temperatures
RSK Number
7110772
Floor Construction
Concrete flooring
Floor Covering
Concrete/Resin/Tiles/Vinyl
Function
Side outlet
Item Color
White
Material
PEH, ABS
Outlet Dimension
Ø75 mm
Pressure Flow Temp
1,0 l/s
Size
Ø150 mm
Version
With water trap
